Equipment Model | N6130 | N6143 | N6155 | N6165 | |||
Cutting rotor diameter(mm) | 300 | 430 | 550 | 650 | |||
Equipped with motor power(kw) | 22 | 45-55 | 55-75 | 75-90 | |||
Equipped with diesel engine model | 25.32HP | Z4102(With pressurization) | Z4105(With pressurization) | Z6105(With pressurization) | |||
Feeding roller diameter(mm) | 280 | 350 | 400 | 500 | |||
Feeding throat size(mm) | 300*200 | 410*310 | 480*440 | 600*500 | |||
Processing diameter(mm) | ≤100 | ≤150 | ≤230 | ≤300 | |||
Productivity(kg/h) | 1500 | 2500 | 4500 | 6500 | |||
Dimensions(mm) | 2300*1300*1800 | 2800*1800*2500 | 3200*1800*3000 | 3800*2000*3200 | |||
Discharge method | 360 degree rotation spray | ||||||
Walking method | moveable and full support type | ||||||
Startup mode | electric starter |
