Home /Products/Biomass Pellet Making Machine/Make Biomass Pellets Biomass Pellet Making Machine Biomass Wood Pellet Machine

Make Biomass Pellets Biomass Pellet Making Machine Biomass Wood Pellet Machine

1.0 Sets
MOQ
Make Biomass Pellets Biomass Pellet Making Machine Biomass Wood Pellet Machine
Features Gallery Product Description Request A Quote
Features
Specifications
Condition: New
Raw Material Processed: Grass, Rice Husk, Wood Sawdust, Biomass, Straw, Cotton Stalks
Pellet Diameter (mm): 2 - 10
Output (kg/h): 500 - 2000 Kg/h
Voltage: 380 V
Dimension(L*W*H): 1400*750*1550 Mm
Power (kW): 45 Kw
Warranty: 1 Year
Applicable Industries: Farms, Energy & Mining
Key Selling Points: Long Service Life
Weight (KG): 2400 KG
Marketing Type: New Product 2020
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Warranty Of Core Components: 1 Year
Core Components: Bearing, Motor
Name: Wood Pellet Making Machine
Application: Make Biomass Pellets
Product Name: Wood Pellet Mill Flat Die Wood Pellet Machine Wood Pellet Hammer Mill
Capacity: 1-1.5t/h
Type: Vertical Rind Die Pellet Mill
Color: Clients' Requirement
Raw Material: Sawdust\straw\rice Husk\wood Waste
Keywords: Pellet Making Plant
Pellet Size: 4-12 Mm
Moisture Of Raw Material: 15-20%
After-sales Service Provided: Online Support
After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: None
Showroom Location: None
Certification: ISO9001
Basic Infomation
Certification: ISO9001
Payment & Shipping Terms
Packaging Details: The surface of the machine is covered with multiple layers of plastic film to ensure that the machine is not oxidized by sea. Customers have special requirements can be negotiated
Supply Ability: 100 Set/Sets per Month
Product Description
Product Description

Biomass pellet machine is a kind of biomass energy pretreatment equipment. It mainly uses biomass from agriculture and forestry processing such as wood chips, straw, rice husks, bark and other biomass as raw materials. Through pretreatment and processing, it is solidified into high-density particulate fuel. Biomass pellet machine is divided into flat-die biomass pellet machine and ring-die biomass pellet machine.biomass pellet making machine biomass wood pelleting machine
Parameter
Model
YB-450
YB-550
YB-750
YB-900
Power(KW)
45
55
75
90
Spindle Speed(r/min)
1450
1450
1450
1450
Die diameter(MM)
400
450
500
550
Output Size(MM)
4-12
4-12
4-12
4-12
Granulation Temperature(℃)
80-100
80-100
80-100
80-100
Raw material moisture(%)
15-25%
15-25%
15-25%
15-25%
Voltage(V)
380
380
380
380
Capacity(t/h)
0.6
0.8
1-1.2
1.2-1.5
Size(mm)
1400*750*1550
2600*1300*2300
3500*1600*3200
4600*2300*3800
Weight(T)
2.9
3.6
5.6
6.8
Features ＆ Advantages
Pellet fuel is produced by pressing raw materials such as wood chips and straw under pressure at normal temperature using a roller and a ring die. The density of raw materials is generally about 0.6-0.8, and the density of particles after molding is greater than 1.1, which is extremely convenient to transport and store. At the same time, its combustion performance is greatly improved,reducing human dependence on petrochemical energy and atmospheric emissions.biomass pellet making machine biomass wood pelleting machine
Applicable
The use of biomass fuels is a new type of bio-energy. It can replace wood, raw coal, fuel oil, liquefied gas, etc. It is widely used, such as:
1. Civil heating and domestic energy: high fuel utilization and easy storage.
2. Biomass industrial boiler: as the main fuel for industrial boilers, replacing coal combustion, reducing atmospheric emissions and pollution.
3. Power generation: It can be used as a fuel for thermal power generation.
Product Details
1. It adopts high-precision involute cylindrical helical gear direct transmission, with a transmission efficiency of more than 98%, which is 20 ~ 25% higher than the production efficiency of traditional belt granulators;biomass pellet making machine biomass wood pelleting machine 2. The gear teeth of the transmission gear are normalized heat-treated after water forging to increase the hardness of the tooth surface. The tooth surface is treated with carburizing. The depth of the carburized layer is 24mm to enhance the wear resistance and prolong the service life of the parts. Silent fine grinding repair process, making the operation quieter and more stable; 3. The bearings used in the particle forming system are all high-quality silent bearings, and the thin oil circulation cooling and lubrication system is added to ensure longer bearing life and safer operation; 4. Press roller automatic adjustment function: the principle of bidirectional rotation of the thrust bearing is used to automatically adjust the pressure angle, so that the material is not crowded, and the machine is not stuffy, ensuring the stability of the material forming;biomass pellet making machine biomass wood pelleting machine
PACKING &SHIPPING

* Payment:

T/T, Western Union, L/C, Paypal, Secure payment of Alibaba.
* Delivery time:

We will deliver within 7-15 working days after receiving front payment.
* Package

Wood Case, Films, or according to buyers’ requirement.biomass pellet making machine biomass wood pelleting machine
Company Profile
Henan Yibao Machinery Equipment Co., Ltd. has established a good market reputation in a short time with good product quality,thoughtful after-sales service and honest management style, and has established a good corporate image among many users.
Let the world fall in love with Made in China! !!
FAQ
1. Could I have prices of your products ? Welcome. Pls feel free to send us an email here. You will get our reply in 24 hours. 2. Can we customize our logo/website/company name on products? Yes, we offer OEM and ODM service. 3. Can I get a discount? Yes, the more quantity, the better the price. Please contact us to get the best price. 4. Do you inspect the finished products? Yes, each step of production and finished products will be came out inspection by QC department before shipping. 5. Where are you? Can we go to China and visit your factory? Yes, of course. We are in Henan, China. Welcome to our factory.
